Product Description
Vinyl paper plotter cutter plotter Graphtec CE
5000 series digital cutting plotter
Specifications
Vinyl paper plotter
Especially Deigned
Manufactured
Higher level
colors available
The Superior
price/performance of the CE5000 transforms cutting jobs.
The Superior
price/performance CE5000 Series cutting plotter offers performance comparable
to high-end units at reasonable cost. In addition to outstanding basic
performance, the CE5000 incorporates arrange of features such as registration
mark detection to ensure high-precision cutting of printed materials. This
plotter helps increase work efficiency and productivity.
Incorporates ARMS to ensure precise cutting.
The ARMS automatic registration mark sensing
function detects printing positions for high-precision cutting.
The outstanding ease-of-use and performance of the ARM function increases label
and sticker productivity.
Four-point registration mark (two axes skew)
correction
Four-point registration mark sensing and X/Y-axis
correction (Graphtec original two-axis skew correction) uses high-precision
positioning to ensure accurate cutting of graphics that have been skewed or
distorted during printed.
Multiple registration mark correction
Layout instructions are sent together with the
cutting data for design sprinted using layout functions such as RIP, enabling
continuous detection of registration marks for cutting. This significantly
reduces work times and increases productivity.
Segment area correction
The intermediate registration marks in the media
feed direction are detected to allow four-point correction for each individual
segment area. This enables high-precision positioning of the whole area of
skewed prints produced using long-length printing.
Automatic registration mark detection
The first registration mark is detected
automatically, eliminating the need to move the sensor to the registration mark
manually.
Subsequent registration marks are automatically redetected even if sensing
errors occur, simplifying the process of registration mark sensing.
Supports registration mark commands
Registration mark commands are provided to
control ARMS functions from a PC.
Registration mark data including size and spacing can be controlled to simplify
operations.
Includes a range of
software applications that improve work efficiency and simplify operations.
Cutting Master 2
This plug-in application allows direct cutting
from graphics applications. For higher productivity, create graphics or text in
Adobe Illustrator or CorelDraw, then simply output directly to the plotter.
-
Direct output from the software
-
Output by layer / color
-
Possible to check the cutting lines by preview window
-
Multiple over cutting is possible
-
ARMS can be controlled by software
-
Centering, Rotate, Mirror for easy layout
-
Matrix copy for higher productivity
-
Auto-welding for binding same color of shapes
-
Tiling / Paneling for segmentation of cutting
Plotter Controller
This application allows direct control of a wide
range of CE5000 functions from a PC, including cutting speed, cutting pressure,
pen movement, and ARMS control. The ability to control various plotter settings
from a PC dramatically improves work and operating efficiency.
-
Cutting conditions setting
-
Test cut
-
Position move
-
Rotation
-
Origin point
-
Key board control
-
Registration mark setting
-
Auto-mark reading
-
Mark size, distance
ROBO Master Pro
This sign creation application is simple and
easy-to-use, even for first-time users. Create and edit graphics and text for
simple film cutting. The application provides a function for use on stickers or
labels.
-
Edit a design (Shape, True type font)
-
Import the DXF files (R13 format)
-
Direct output from software
-
ARMS can be controlled by software
